High Impact Depth
Hard alloy marking pin for deep indentation on uneven or rugged surfaces.
Industrial Ruggedness
Highly stable mechanical structure designed for 24/7 continuous operation in harsh environments.
Extreme Cost-Effectiveness
Low initial investment and minimal maintenance costs with simple air-powered operation.
About Pneumatic Marking
Pneumatic marking machines utilize high-pressure compressed air to drive a tungsten alloy marking pin, creating permanent indentations through high-frequency impact. This process enables deep and durable marking with high legibility, even on rough or uneven surfaces. Specifically engineered for heavy-duty metal processing, they offer exceptional stability, high impact resistance, and low operating costs. They are widely used in automotive chassis, large-scale steel structures, oil pipelines, heavy machinery, and industrial nameplates, providing reliable identification for harsh industrial environments and high-strength manufacturing.
Technical specifications
| Feature | Parameter | |
|---|---|---|
| Model / Marking Area | 200*130mm/250*150mm/300*200mm | |
| Marking Depth | 0.1-1mm (Depending on material) | |
| User Preparation | PC + Air Compressor | |
| Marking Speed | Approx. 1 character/sec (Adjustable) | |
| Mainboard | Genuine Jiuma Control Board | |
| Air Pressure | 0.3MPa - 0.6Mpa (Recommended: 800W, 30L+) | |
| Voltage | 220V | |
| Applicable Workpieces | Metal parts, Metal plates, PVC workpieces, etc. | |
| Machine Dimensions | 300*330*536mm/330*380*536mm/380*380*536mm | |
| Machine Weight | 18kg/20kg/22kg |
